Vertical semi-automatic press - AutoLoadBaler

Vertical semi-automatic press – AutoLoadBaler

Code: AutoLoadBaler

Semi-automatic baling press for supermarkets for automatical compaction of cartons collected in the trolley.

The smart way to collect – the new way to compact. Using the AutoLoadBaler annually 30 t to 300 t of cardboard packaging can be compacted into direct marketable bales. With the automatic filling the AutoLoadBaler is so far ahead of the conventional balers.

Privalumai:

Convenient collection
Large volume collection trolleys
No precrushing
No filling and waiting times
Less walking routes
Automatic emptying
High time savings
High revenues

Out of stock

Vertical semi-automatic press - AutoLoadBaler

Strautmann's AutoLoadBaler makes pressing extremely effective. We focus on automatization and minimizing time consumption. This system includes a process from automatic filling to automatic bale ejection. Semi-automatic AutoLoadBaler is head and shoulders above standard vertical presses. Automatic filling of the press chamber saves working time.

Cartons are easy filled into the large volume collection trolley. The collection trolley is then pushed into the pressing unit and by pushing the start button the collection trolley is fully automatically emptied.

The collection trolley can be labeled by the customer and used as free advertising space.

The AutoLoadBalerready is equipped with an interface for a later retrofitting of the collecting unit with automatic filling.

	Auto Load Baler ready	Auto Load Baler
Hand wheel	x	x
Sliding door	x	x
Sliding door with automatic opening	opcija	opcija
QuickDoor®	opcija
EasyTie	x	x
Tying with strap	x	x
Tying with wire	x	x
Hydraulical bale ejection	x
BaleMatic®	opcija	x
Press shield guidance TopPlus®	x	x
PowerSave®	x	x
Time control	x	x
CircleSystem®	x	x
Technical data
Pressing force in kN	580	700
Bale weight in kg max.	400	450
Bale dimensions in m (l x b x h)	1,2 x 1,1 x 0,8	1,2 x 1,1 x 0,8
Cycle time in seconds	37	37
Electrical connection	400V 50Hz 4kW	400V 50Hz 5,5kW

Top plus®
Even with uneven filling of the press chamber an unbalance of the press plate is excepted due to the stable press plate guidance TopPlus®.

BaleMatic®
Safe bale ejection by hydraulical ejector and a long lifetime due to the separate cylinder.

QuickDoor®
Space saving swinging-sliding door with automatic opening for a safe and quick filling of the baler. No manual pressing of material into the chamber anymore.

CircleSystem®
Integrated down-holders prevent reexpansion of the material inside the chamber and ensure a higher bale density.

Time control
The press plate compacts the bale with full power for a specific time. Thereby high bale density and bale weights are reached. With pressure control, in contrast, press plate immediately moves up.

EasyTie
The bale is tied ergonomic friendly and fast whilst opened door.

HydroClose
The hydraulical door lock controls the re-expansion forces of big bales. A separate cylinder opens the door controlled and slowly so unexpected opening is avoided.

Integrated strap- & wire hooks
In the press plate integrated strap- and wire hooks ensure an easy, comfortable and fast bale tying.

PowerSave®
Energy-efficient control of the press plate due to the tandem pump. In comparison with single-pump systems 50 % energy costs are saved.

Vertical semi-automatic press – AutoLoadBaler
