Semi-underground system GTC

Code: BAU GTC


Efficient and Accessible Collection of Waste and Recycling Materials – for Housing Complexes, in the Town, for Rest Areas and Recreational Facilities.

Available capacities 2.7 and 3 m³.

Pagrindinės charakteristikos:

  • Designed for everyone - low-level access the container stands in a galvanized ground basin
  • A clear view for all road-users
  • Relatively shallow installation depth, does not interferce with underground cables
  • Easy to instal and inexpensive to move should the neccessity arise
  • Neat appearance - the containers always stand exactly where they are supposed to
  • Sturdy steel sheet construction, welded or screwed together
  • Individual construction on request
  • Much more efficient collection
  • Under ground it’s cooler, more hygienic
  • All of the waste has limited access

Out of stock




Semi-underground system GTC

Construction:

  • Pick-up system for truck crane
  • Collecting container made of galvanized steel sheet
  • 1 or 2 chambers
  • Various throw-ins
  • Basin-like trap doors retain any remaining liquid
  • Glass: trap doors held and operated by high-strength chains, insulated against noise and connected to pick-up system
  • Paper/household refuse: trap doors held and operated by traverse / leverage system which is connected to pick-up system
  • Ground basin is galvanized, 340 or 490 mm deep

Product specifications table


GTC 2700L

GTC 3000L

GTC-D 3000L

Volume (approx. In L)

2700

3000

3000

Dimensions (w x d x h) (approx. In mm) (not incl. Pick-up)

1835 x 1535 x 1300

1835 x 1535 x 1450

1830 x 1530 x 1600

Height visible section (approx. in mm)

990

990

1150

Weight (approx. in kg)

320

345

420

TECHNICAL SPECIFICATION
