Slow-Speed Universal Shredder TEUTON Z 60

Code: Z60

TEUTON Z60 - From initial shredding to the final product with just one machine

TEUTON Z 55 privalumai:

  • 30 interchangeable shredding teeth in three rows distributed over the roller surface
  • Variable final grain size due to tools-less cutting gap adjustment
  • Screen basket system exchangeable without tool use (80 mm - 250 mm)
  • Hydraulically swingable maintenance door for easy access to the shredding chamber
  • Large and wide conveyor belts for maximum material discharge
  • Discharge height up to 5 m
  • Storage space for all options
  • Hydraulic / mechanical driveCentrinis
  • aptarnavimo taškas – palengvinta priežiūrą
  • Central maintenance point – facilitated maintenance
  • Neodym magnetic separator whose working height is hydraulically adjustable allows for discharge of metal scraps on both sides

Out of stock


Slow-Speed Universal Shredder TEUTON Z 60

The new big brother from the EGGERSMANN family!

Mounted on a semi-trailer or crawler chassis, the universal low-speed single-shaft shredder Eggersmann TEUTON Z 60 with 3 m long rotor can quickly, efficiently and efficiently shred a wide range of waste and materials - from wood waste, green waste, stumps to bulky waste, furniture, mattresses, tires as well as plastics and films, household and miscellaneous industrial waste, sleepers, electric cables, etc.
The simple and robust adjustment system between the rotor and the counterblade (over 10 options) and the use of sieves help to obtain the required size fraction after grinding.
Wide and long conveyors ensure efficient machine operation and help prevent blockages. Material discharge height up to 5 m.
A neodymium alloy magnetic separator (optional) with adjustable height above the exhaust conveyor will help separate metallic impurities from the shredded material.

Product specifications table

Overall weight

32 t (semi-trailer) / 34 t (tracks)


Semi-trailer / Crawler chassis


Cummins QSX15 diesel engine

Emission standard

Stage V


447 kW (600 hp)

Number of shafts


Rotor length

3000 mm

Rotor diameter

max. 1050 mm

Number of interchangeable teeth


Rotor speed (adjustable)

max. 40 rpm

Rotor drive

hydraulic / mechanical planetary

Additional equipment available

Interchangeable sieve system, neodymium alloy magnetic separator, on-site drive, hopper lift, etc.
