Screening bucket MB-S14 S4

Code: MB-S14 S4

Compact and easy to transport, thanks to its reduced weight, it is essential in all situations requiring volumetric separation.

The MB-S14 screening bucket has been specially designed for clients who require high performance in small and medium-scale sites.

Sijojimo kaušas tinka:

  • Excavators between 9 and 20 Ton

Out of stock


Screening bucket MB-S14 S4

The screening buckets MB are equipped with baskets formed by interchangeable modular panels, available with holes of different sizes based on requirements.

Primary screening of scrap material, demolition material, filling material for excavations, and material resulting from the reclamation of rocky soil
Selection of pebbles in waterways
Cleaning of beaches
A crucial piece of equipment in all situations were smaller pieces need to be obtained

Perfect for the screening and selection of natural materials, both before and after the crushing phase, the MB-S Screening Buckets reduce crushing times by up to 60%, consequently allowing you to salvage materials suited to the type of job being carried out, and to manage them in the best way possible.

Product specifications table


MB-S10 S4

MB-S14 S4

MB-S18 S4


Recommended excavator

≥ 3,5 Ton

≥ 9 < 20 Ton

≥ 20 < 35 Ton

≥ 35 Ton

Recommended backhoe/mini excavator

*≥ 4 < 9 Ton


0,39 Ton

1,10 Ton

2 Ton

3,75 Ton

Load capacity

0,32 m³

1,10 m³

2,40 m³

4,30 m³

Pressure/Counter pressure

130 bar

150 bar

200 bar

320/5 bar

Oil flow

40 l/min

60 l/min

120 l/min

160 l/min


MB Brochure 2018

MB-S14 S4 Brochure
